Model No.

YDQW22LF

General

Main processor

Ingenic-T31ZL

APP Operation System

Android, IOS

Image Senor

1/3″ Image Sensor

Compression

H.264+/H.265

Resolution

1920*1080 1080P

Internet Connection

WIFI

2.4GHz WIFI

Alarm

Detection Mode

PIR Human detection + AI Human shape detection

Detection Distance

0~12M

Detect Angle

105°

Alarm Mode

Realtime calling or push message

PTZ

PTZ Angle

Horizontal 355 ° Vertica 100°

Speed

Horizontal 55 °/S Vertical 40°/S

Night Vision

Full color night vision

0.001 Lux

IR LED

infrared LED 25M IR distance

White light LED

white light LED 25M distance

 Audio

Built-in speaker (input)

3W

Built-in microphone (output)

voice monitoring distance 10M

Lens

Lens

2.8mm

Lens Angle

105°

Storage

Cloud Storage

Cloud storage, storage when alarm recording

Local Storage

TF Card Max 128G

Power

Power Supply Mode

Solar Panel+ Build in Batteries

Panel Material

monocrystalline silicon

Solar Energy Power

3.5W

Battery Capacity

Build in 3pcs 21700 battery ( 15000MAH  )

Operating power consumption

Max 4W

Standby consumption

0.003W

Others

Working Environment

Indoor/outdoor

Operation Temperature

-30°~+60°

Humidity

0%~90%RH
