- YDJP08JBK
Order Models： YDJP08JBK(8MP)
Operate APP: Eseecloud or XMeye
Support Service: OEM APP / Package OEM / OEM Logo / OEM Logo
NVR Parameters :
|
Video Inout |
8CH 5MP/8MP |
|
Bandwidth |
70Mbps |
|
HDMI |
1CH, HDMI interface; resolution:5.0MP/30Hz; |
|
Audio |
1*3.5mm earphone port, support HDMI Audio output |
|
Video Compression Standard |
H.265;H.264+ |
|
Playback |
8CH 5MP Recording;2CH 5MP Playback |
|
Coding Resolution |
5MP/8MP recording coding |
|
Stream Type |
Audio/Video Stream,VBR / CBR |
|
Audio Compression Standard |
G.711 |
|
Recording Mode |
Manual/Time/Motion Detection/Alarm Recording |
|
Playback Mode |
Normal Playback |
|
Back-up Mode |
USB back-up&Internet Back-up,Time Back-up |
|
Storage Type |
Support 1*SATA |
|
Storage Space |
Max. up to 6TB HDD |
|
Interface |
8 port, RJ45 10M/100M auto-adaption Ethernet |
|
Type |
IEEE802.3af |
|
Output Power |
≤13W |
|
Internet Port |
1* RJ45 100M auto-adaption ethernet |
|
USB Port |
2*USB 2.0 Interface |
|
Internet Protocols |
UPnP、SNMP、NTP、SADP、SMTP、PPPoE、DHCP |
|
Work Temperature |
-10°---- 55° |
|
Device Control |
Remote Control & Mouse |
|
Power Input |
DC +48V |
POE 5MP Camera Features:
|
Operation System |
LiteOS,Embedded Linux real-time operate system |
|
Image Sensor |
1/2.9” CMOS Sensor |
|
Resolution |
HD 5MP 4 : 3 |
|
illumination |
Color: 0.1 Lux,Black/White: 0.01 Lux |
|
Video Process |
H.264/H.265 Video coding, support double-stream |
|
Image input |
Main stream: 2560*1920@25fps; sub-stream:640*360@25fps |
|
Day&Night Switch |
Auto/ Colorful/ Black&White |
|
3D R&D |
Auto |
|
Mir/Flip |
YES |
|
Video Coding |
Dual-Stream:H.264/H265 5mp@30ps; |
|
Audio Coding |
G.711 A-Law @ 16bits 8kbps |
|
Audio I/O |
Support |
|
Pan/Tilt |
Support（Horizontal 355°Vertical 89°） |
|
Lens |
3.6mm |
|
Power in |
DC12V/1A or POE 48V |
|
Cloud storage |
YES |
|
Reset interface |
YES |
|
SD Card |
No |
|
Other functions |
Motion detection;Alarm message push; support phone/pc view remotely;Color: Black/White |
