16CH 4K WIFI NVR

Compression format

H.264&H.265 Embedded Linux Operation System

Channels

16CH 4K

Video Input

16ch wireless or RJ 45 Interface

HDMI Output

HD 1080P / 2K

Internet connection

2.4g & 5.8g connection

Recording & Playback

16 ch 3MP Recording & 4ch Playback

16ch 4MP Recording &4ch Playback

16ch 5mp Recording & 2ch Playback

16ch 8mp Recording &1CH Playback

Internet Protocol

UPnP ,SMTP ,PPoE ,DHCP

Storage

3.5 inch HDD Max. 6TB

Backup

USB / Internet Cloud

Network

RJ45 10M / 100M Internet Interface

USB Interface

1 * USB2.0 or 2*USB 2.0 Interface Option

Device Control

USB Mouse

Power

12V /3A Power

Work Tem.&Hum

-10°~ 55°, ≤95%

WIFI Dual lens PTZ  camera

Pixel

4MP

Sensor

1/3” CMOS Sensor*2

Lens

4mm & 4mm lens

Camera

PTZ camera *1 & Bullet camera*1

Resolution

Main stream:2880*1080@15fps;

Sub stream:1200*448@15fps

Frame rate

15fps

Compression

H.264/H.265 Video encoding, supports dual streams

Audio

AAC、G711

Audio enabled

2-way Audio

WIFI

2.4g & 5.8g

Support agreement

Support N1 agreement

Min. Illumination

Color: 0.1Lux,B/W 0.01 Lux

IR LED

12pcs full color Leds

Full light length

IR: 15M (varies by environment)

Power

DC12V
