System

Ios,android system

Multi-language, multi-category, universal, support OEM and ODM customization

Local storage

Support external 8-128GB MicroSD card, 24 hours video recording.

Online upgrade

Easily realize remote OTA online upgrade through Tuya Cloud, the latest version quickly upgraded

Services

Support Tuya cloud storage function, Amazon Echo/Google Chromecast service optional

Operate system

inux operating system, with high-performance DSP processor FH8852V200

Image sensor

1/2.7’ CMOS (SC3335)

External-

interface

TF card

Max.128g

Reset switch

yes

Video

Video Show

16:9

Compression

H.265/H.264

Stream

Main stream：300W@15fps

Sub-stream：200W@10 fps

Resolution

Main stream：2304*1296  15fps

Sub-stream：640*360 10fps

Illumination

O.O2Lux@(2.0,AGC ON),0Lux with IR

Video code

Main stream：1Mbps

Sub-stream：512Kbps

Lens

Option（3.6/6/8mm）

Others

mirror/flip

YES

S/N

3D /72DB

Motion detection

YES

Two way audio

YES

Audio input

YES

Audio output

1 CH

Anti-flash

Outside /50 Hz /60Hz

Ir cut

 4 ir infrared+4 white-light

WIFI

2.4G，

Cable connection

yes

Add terms

QR CODE, AP, CABLE CONNECTION, MATCH CODE

Internet protocol

HTTP,HTPPS,TCP,IPV4,IPV6,UDP,RTSP,ICMP,RTP,DHCP,ARP,DNS,QoS

PT

Horizontal: 355/Vertical: 89
